Backyard Discovery Aurora - Ladder Assembly Instructions

Ǣǻrƻˠ
LADDER ASSEMBLY
˟˥ˢ ʹɮ˧ʺ
Dŷĵǻ˚ˢˀˣ˃
ˠ˟˧ ʹɮ˧ʺ
ɟǢËrNJ˚˧ɮˠˤ
˟˦ˡ ʹɮ˧ʺ
ǻ˚ŗȕǻ˚ˠˀˣ˃
ĵˣ ʹɮˣʺ
ĵ^^rNJNJȕŗµ
BOLT PTH
1/4x3/4
(x8)
H100063
WASHER
LOCK INT
8x15
(8)
H100108
T-NUT
1/4
(x8)
H100072
˟ˣ˟ ʹɮˣʺ
DĵȕrËNNJŷNħ˞ˡ
BLUE HC ROCK #2
(x4)
A6P00040
LADDER RUNG - W4L13286
5/8"x4 3/8"x16 7/8" (16x112x430)
L4
(x4)
LEFT RUNG ASSEMBLY (x2)
RIGHT RUNG ASSEMBLY (x2)
TIP:
INSTALL THE T-NUTS FIRST
20
