Backyard Discovery Aurora - Slide Assembly Instructions

PRE-BENDING THE ENDS WILL EASE ASSEMBLY.
ǻÝƻʲ
BOLT WH
5/16x1/2
(2)
H100115
T-NUT
5/16
(2)
H100074
Ǣǻrƻˠ
PLACE 'M77' SLIDE BRACE BOARD 1/2" FROM THE BOTTOM EDGE OF THE SLIDE BED. USING THE BOARD AS A TEMPLATE,
MARK WHERE THE PILOT HOLES WILL BE DRILLED. USE A 3/8" DRILL BIT TO DRILL THE PILOT HOLES INTO THE SLIDE BED.
ATTACH THE SLIDE BED SUPPORT BOARD USING THE HARDWARE PROVIDED.
ˠˠˤ ʹɮˡʺ
Dŷĵǻ˚ˠˀˡ˃
˟˦ˣ ʹɮˡʺ
ǻ˚ŗȕǻ˚ˤˀˠ˥˃
SLIDE ASSEMBLY
ō˦˦ ʹɮˠʺ
ǢĵÝ^rDNJNr
6 FT SLIDE BED
(1)
A6P00404

SLIDE BRACE - W4L13297
5/8"x3 3/8"x14 1/4" (16x86x362)
M77
(1)
ˣ˟ˣ ʹɮˠʺ
˥®ǻǢĵÝ^rDr^
