Backyard Discovery Aurora - Page 43

FORT ASSEMBLY
Ǣǻrƻˠ˥
90° L-BRACKET -
BLK
(2)
A4M01110
BOLT WH
5/16x1-1/2
(4)
H100010
WASHER LOCK
EXT
8x19
(4)
H100030
T-NUT
5/16
(4)
H100074
BOLT WH
1/4x5/8
(2)
H100490
TOP RAIL - W4L13280
5/8"x2 3/8"x36 5/8" (16x60x930)
N5
(1)
TOP RAIL - W4L13229
5/8"x2 3/8"x21 1/8" (16x60x538)
N4
(2)
WASHER LOCK
EXT
8x15
(2)
H100139
BOLT WH
1/4 x 1/2"
(2)
H100141
NUT BARREL WH
1/4x5/8
(2)
H100136
T-NUT
1/4
(2)
H100072
˟˦ˡ  ʹɮˡʺ
ǻ˚ŗȕǻ˚ˠˀˣ˃
ˠˣˠ ʹɮˡʺ
Dŷĵǻ˚ˠˀˡ˃
ˣ˨˟ ʹɮˡʺ
DŷĵǻɟË˚ˤˀ˧˃
ˠˢ˥ ʹɮˡʺ
ŗȕǻDNJNJrĵ˚ˤˀ˧˃
ˠˢ˨ ʹɮˡʺ
ɟǢËrNJ˚˧ɮˠˤ
˟ˢ˟ ʹɮˣʺ
ɟǢËrNJ˚˧ɮˠ˨
˟ˠ˟ ʹɮˣʺ
Dŷĵǻ˚ˠˠˀˡ˃
˟˦ˣ ʹɮˣʺ
ǻ˚ŗȕǻ˚ˤˀˠ˥˃
ˠˠ˟ ʹɮˡʺ
˨˟ĵ˚DNJNħrǻ˚Dĵħ
ŗˤ ʹɮˠʺ
ŗˣ ʹɮˡʺ
43
