Backyard Discovery Highlander 6010 - Page 20

1/4"
BARREL
HEAD
NUT
H100079
1/4 X 1"
STEP
BOLT
H100064
1/4 X 1"
PHILLIPS
TRUSS
HEAD
BOLT
H100061
#8 X 1-1/4"
WOOD
SCREW
H100087
#8 X 1-1/2"
WOOD
SCREW
H100086
#8 X 2"
WOOD
SCREW
H100111
DRAWINGS ARE TO SCALE BUT SMALL VARIATIONS ARE NORMAL.
5/16 X 3-3/4"
HEX
HEAD
BOLT
H100051
5/16 X 1 1/4"
HEX HEAD
BOLT
H100042
0
1
2
3
4
5
6
7
8
9
MEASURE BOLTS FROM BOTTOM
OF HEAD TO BOTTOM OF BOLT
5/16 X 2"
HEX
HEAD
BOLT
H100044
3/8 X 6 1/2"
HEX
HEAD
BOLT
H100059
5/16 X 1 3/4"
HEX
HEAD
BOLT
H100043
5/16 X 4"
HEX
HEAD
BOLT
H100052
3/8 X 5 3/4"
HEX
HEAD
BOLT
H100117
5/16 X 5 3/4"
HEX
HEAD
BOLT
H100056
H100069
5/16 X 3"
LAG
SCREW
MEASURE BOLTS FROM BOTTOM
OF HEAD TO BOTTOM OF BOLT
H100116
5/16 X 2-3/8"
LAG
SCREW
5/16 X 2"
LAG
SCREW
H100067
5/16 X1 1/2"
LAG
SCREW
H100066
H100090
#8 X 2-1/2"
WOOD
SCREW
H100073
3/8"
SPIKE TEE
NUT
H100074
5/16"
SPIKE TEE
NUT
1/4 X 3/4"
PHILLIPS
TRUSS
HEAD
BOLT
H100063
PAGE 18 - HARDWARE
1/8"
Allen
Wrench
