PAGE 23
STEP 3
Attach G5 Wall Rail to B2 Middle Tower Legs between B2 and
B1 Tower Legs using 5/16”x 4” Hex Bolts, 5/16” Lock
Washers, and 5/16” Spike T-Nuts. (Note
position of arch).
Attach H4 Floor Rail to B1 Front Tower Legs using
5/16”x 4” Hex Bolts, 5/16” Lock Washers, and
5/16” Spike T-Nuts. (Note position of holes toward right side
front).
Fender Washers
Fender Washers
G6
G7
G7
B1
B1
B2
B3
G5
G6
G7
G7
B1
B1
B2
B3
G5
H4
ITEMS NEEDED
(1) G5 Wall Rail
(1) H4 Floor Rail
HARDWARE NEEDED
(4) 5/16” x 4” Hex Bolt
(4) 5/16” Spike Tee Nut
(4) Fender Washers
(4) 5/16” Lock Washer
