Backyard Discovery HILLCREST - Page 53

CENTER WINDOW
IN OPENING
STEP 24 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
8 H100070
SCREW PWH 8x3/4
10 H100088 SCREW PFH 8x1-1/8"
070 (x8)
SCREW - 8x3/4"
088 (x10)
SCREW - 1 1/8"
010 (x2)
PLASTIC WINDOW BYD GREEN 343x444.5
WALL SUPPORT - W4L16081
5/8"x1 3/8"x13" (16x34x330)
O01
(x2)
PLASTIC
WINDOW BYD
GREEN
343x444.5
(x2)
A100010
2 1/4 in
[57 mm]
O01 (x2)
