Backyard Discovery HILLCREST - Page 54

1 1/8 in
[30 mm]
2 7/8 in
[73 mm]
1 1/8 in
[30 mm]
3 1/4 in
[83 mm]
STEP 25 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
12
H100086
SCREW PFH 8x1-1/2"
WINDOW SHUTTER SLAT - W4L16084
5/8"x1 3/8"x5 3/8" (16x34x136)
O04
(x6)
WINDOW SHUTTER - W4L16042
5/8"x4 3/8"x16" (16x112x406)
L04
(x3)
SIDE VIEW
CORRECT BOARD ASSEMBLY
086 (x12)
SCREW - 1 1/2"
O04 (x6)
L04 (x3)
54
