STEP 26 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
1
H100005
NUT BARREL WH 5/16x7/8
1 H100008 BOLT WH 5/16x1
1
H100031
WASHER LOCK EXT 12x19
1 H100074 T-NUT 5/16
14 H100088 SCREW PFH 8x1-1/8"
1 H100115 BOLT WH 5/16x1/2
L BRACKET
2.5x38x55x55
(x1)
A4M01046
WALL BOARD - W4L16052
5/8"x3 3/8"x21" (16x86x532)
M16
(x2)
WALL BOARD - W4L16060
5/8"x3 3/8"x5" (16x86x126)
M29
(x2)
WALL BOARD - W4L16064
5/8"x3 3/8"x35" (16x86x888)
M28
(x1)
WALL BOARD - W4L16044
5/8"x3 3/8"x35" (16x86x888)
M10
(x1)
074 (x1)
T-NUT - 5/16"
031 (x1)
WASHER - 12x19
005 (x1)
NUT BARREL - 7/8"
008 (x1)
BOLT - 5/16x1"
088 (x14)
SCREW - 1 1/8"
115 (x1)
BOLT - 1/2"
USING L BRACKET AS A GUIDE,
DRIL
L (1) 3/8 in [10 mm] HOLES
THRU FLOOR FOR HARDWARE
1046 (x2)
L BRACKET
2.5X38X55X55
M10 (x1)
M28 (x1)
M29 (x1)
M16 (x2)
