Backyard Discovery HILLCREST - Page 56

CENTER WINDOW IN OPENING
STEP 27 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
4
H100070
SCREW PWH 8x3/4
4 H100088 SCREW PFH 8x1-1/8"
WINDOW
216x267 GREEN
(x1)
A100146
WALL SUPPORT - W4L16082
5/8"x1 3/8"x10" (16x34x254)
O02
(x1)
070 (x4)
SCREW - 8x3/4"
088 (x4)
SCREW - 1 1/8"
O02 (x1)
146 (x1)
WINDOW 216x267 GREEN
2 1/4 in
[57 mm]
56
