Parts Identification
Wood Components
(NOT TO SCALE)
M27 - WALL BOARD - W4L06534
5/8"x3 3/8"x48" (16x86x1219)

M28 - WALL BOARD - W4L06535
5/8"x3 3/8"x29 7/8" (16x86x760)

M29 - WALL BOARD - W4L06536
5/8"x3 3/8"x8 1/4" (16x86x210)

M30 - WALL BOARD - W4L06537
5/8"x3 3/8"x26 7/8" (16x86x684)

M31 - GABLE BOARD - W4L06538
5/8"x3 3/8"x41 3/8" (16x86x1052)

M32 - GABLE BOARD - W4L06539
5/8"x3 3/8"x41 3/8" (16x86x1052)

M33 - FASCIA BOARD - W4L06559
5/8"x3 3/8"x25 5/8" (16x86x652)

M34 - FASCIA BOARD - W4L06560
5/8"x3 3/8"x42" (16x86x1068)

M35 - STAIR BOARD - W4L06618
5/8"x3 3/8"x20 5/8" (16x86x525)

M70 - SLIDE BED SUPPORT - W100935
5/8"x3 3/8"x19 7/8" (16x86x505)

M73 - REAR SUPPORT - W4L06608
5/8"x3 3/8"x19 1/4" (16x86x488)

M36 - FILLER BOARD - W4L06800
5/8"x3 3/8"x3" (16x86x76)

M37 - FILLER BOARD - W4L06801
5/8"x3 3/8"x6 3/4" (16x86x170)

M38 - SAFETY BOARD - W4L07011
5/8"x3 3/8"x54 3/8" (16x86x1380)

M110 - ATTACHMENT BOARD - W4L06610
5/8"x3 3/8"x19 1/4" (16x86x488)

