STEP 12
ELECTRICAL ENCLOSURE
(x1)
9205413
SCREW RAISED HEAD
8x1 1/2
(x4)
H100966
(INCLUDED WITH ELECTRICAL ENCLOSURE)
413
(x1)
ELECTRICAL ENCLOSURE
966
(x4)
SCREW - 1 1/2"
REFER TO ELECTRICAL ENCLOSURE
MOUNTING INSTRUCTIONS.
28
