Made in China | INS-9205413-A-POWERPORT-ENG 2-3-2022
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
800-856-4445
PowerPort™
Model # 9205413
Wood Post Mounting Instructions
2 3/8 in [60 mm]
20 1/8 in [512 mm]
966
(x4)
SCREW - 1 1/2"
413
(x1)
ELECTRICAL
ENCLOSURE
SCREW RAISED HEAD
8x1 1/2
(x4)
H100966
ELECTRICAL ENCLOSURE
(x1)
9205413
ENSURE THAT CORD END IS NOT
WITH-IN 6"- (152mm) OF THE GROUND
WHEN MOUNTING.
2 3/8 in [60mm]
20 1/8 in [512mm]
PRE-DRILL 1/8 IN - (3mm) PILOT HOLES
USING THE DIMENSIONS PROVIDED.
POST
