STEP 24:
LEFT
SCREW PFH
8x2 1/2
(2)
SCREW PFH 8x2 1/2
(2 PLCS)
H3
19 5/16"
LEFT
H3 - SHELF SUPPORT - W4L07209
1"x3 3/8"x4 3/4" (24x86x120)
(2)
