STEP 52:
(1) BENCH ASSEMBLY
WASHER LOCK EXT 8x15
(2 PLCS)
NUT BARREL WH 1/4x5/8
(2 PLCS)
BOLT WH 1/4x1
(2 PLCS)
BOLT WH
1/4x1
(2)
NUT BARREL
WH 1/4x5/8
(2)
WASHER
LOCK EXT
8x15
(2)
BENCH ASSEMBLY
