Backyard Play Systems 5027 - Page 27

23
FORT
FORT
BALUSTER SUPPORT
BALUSTER SUPPORT
x1
1 x 3-1/2 x 22-1/2"
2861-CC
Flush
Flush
Flush
Mark and drill 1/4" x 2" DEEP pre-drill before installing lag bolt.
Bottom rests ush
on lower brace.
x1
3" Wood Screw
x1
2" Wood Screw
x12
2-1/2" Wood Screw
Flat Washer
Lock Washer
3" Lag Bolt
x2
3/4 x 3-1/2 x 45-1/8"
2856-CC
