78
TERRACE BRACETUBE SLIDE
TUBE SLIDE
ASSEMBLY AND INSTALLATION
REFER TO THE TUBE SLIDE MANUAL FOR STEPS TO ASSEMBLE
AND ATTACH THE TUBE SLIDE AND TUBE SLIDE SUPPORTS
TO THE PLAY SET.
AFTER ASSEMBLING AND MOUNTING THE TUBE SLIDE, BE
SURE TO FOLLOW INSTRUCTIONS TO APPLY SURFACING
MATERIAL UNDER THE SLIDE.
Flush
3" Wood Screws
x5
31-1/2"
STOP!
STOP!
1 x 3-1/2 x 27-9/16"
x1
X27090308-ST
To Next Page
