32
STEP LADDER
STEP LADDER
INSTALL
INSTALL
Flush
Flush
Pre-drill two 1/4" pilot holes at marked locations.
Re-drill holes from opposite side using 3/8" bit.
SEE PAGE 7
BACK SIDE
5/16" T-Nut
x2
5/16" x 1-1/4" Button
Head Screw
5/16" Lock Washer
5/16" Flat Washer
x2
