BALUSTERS
INSTALL
FRAME
ASSEMBLE
Note hole locations (2)
BOTTOM
Flush
Flush
Flush
90°
90°
T-Nut
T-Nut
x2
2" Wood Screws
x24
Flush
Flush
Flush
Flush
Flush
62-3/4"
27-1/2"
x2
1 x 3-1/2 x 45-1/8"
2876-CC
x2
3/4 x 3-1/2 x 45-1/8"
2870-CC
FLIP FRAME OVER TO
INSTALL BALUSTERS
Ensure Frame is square before
installing wood screws.
Space all Balusters 1/2" apart.
End balusters 5/8" from frame uprights.
Flush along bottom
BOTTOM
1/2" 1/2" 1/2" 1/2" 1/2"
1/2" 1/2" 1/2" 1/2"
5/8" 5/8"
1-1/4" Wood Screws
x40
x10
5/8 x 3-1/4 x 27-1/2"
2873-CC
Ensure Balusters are evenly spaced
installing wood screws.
x2
1-3/8 x 3-3/8 x 90-1/2"
2881-CC
