Backyard Play Systems 5027 - Page 59

55
FORT
BAY WINDOW
FORT
BAY WINDOW
1-1/4" Wood Screws
x8
x4
2855-CC
5/8 x 3-1/4 x 14-3/4"
FlushFlush
Flush
OUTSIDE VIEW
HINT: Pre-drill at each location to
avoid splitting.
#8 x 3/4" Flat Head
Phillips Screws
x20
x2
PF2990
2855-CC
EQUAL
SIDE VIEW
EQUAL
EQUAL
EQUAL
OUTSIDE VIEW
