63
FLAGS
ACCESSORIES
MONKEY BARACCESSORIES
Locate ag base EQUALLY from top, bottom
and end of upper top rail (Fig. 1).
Assemble ag as shown.
Attach Flag with 4 screws.
1
2
3
EQUAL
Fig. 1
Flag Base
3/4" Truss Head
Screws
x4
EQUAL
EQUAL
FRONT SIDE
x2
BEGIN ASSEMBLING AND INSTALLING MONKEY BARS HERE.
NOTE:
Use this manual instead of the manual
in the Monkey Bar box.
