66
MONKEY BAR
TOP RAIL
2-1/2" Pan Head Screw
1/4" Lock Washer
x2
1-1/2 x 3-1/2 x 78"
2154-CC
x5
PF 4972
1" x 18-1/2"
MONKEY BAR METAL PARTS
x2
Flat Metal Bracket
Top Rung End Rung
x5
18-1/2" 21-1/2"
x3
2023 PF 4972 PF 3297
FASTENERS FOR METAL RUNGS
x16
x16
1/4"
2-1/2"
Lock
Washer
Flat
Washer
x2
L-Bracket
Pan Head Screw
2084
x10
Flat side against wood.
