Backyard Pro Patio Series - Support Structure Assembly

7
ASSEMBLY INSTRUCTIONS
7
ASSEMBLY INSTRUCTIONS
3
3. Unsrew any pre installed (M3/16)
screws(AA) first. Assemble the four
lower supports (H) to the base (J) and
middle plate（F）using the (M3/16)
screws (AA).
4. Unsrew any pre installed (M3/16)
screws(AA) first. Assemble the four upper
supports (C) to the lower supports (H)
using the (M3/16) screws (AA).
The damper (B) is then assembled to the
upper supports (C) using the (M3/16)
screws (AA).
H
AA
J
4
B
C
3. Unscrew any pre-installed (M3/16)
screws (AA) rst. Assemble the four
lower supports (H) to the base (J) and
middle plate (F) using the (M3/16)
screws (AA).
4. Unscrew any pre installed (M3/16)
screws(AA) rst. Assemble the four
upper supports (C) to the lower
supports (H) using the (M3/16) screws
(AA). The damper (B) is then assembled
to the upper supports (C) using the
(M3/16) screws (AA).
