12"
(30,5 cm)
6"
(15,2 cm)
97-1/2"
(247,7 cm)
Flush
For squareness, maintain 3/4"
and 97-1/2" measurements.
For squareness, maintain 3/4"
and 97-1/2" measurements.
28
Place RIGHT panel on back frame as shown with primed side facing up.
2
Use a 3/4" gauge block at edges of panel.
Secure with 2" nails spaced 6" apart on edges and 12" apart inside panel. .
Do not nail
in groove.
BACK WALL PANELS
2" (5 cm)
PARTS REQUIRED:
x32
3/4" GAUGE
BLOCK
DOOR
Your back wall panels are secured to the framing.
FINISH
To draw panels tight at
seams angle nail.
Gauge Block
x1
3/8 x 48 x 84"
(1 x 122 x 213,4 cm)
To Next Page
