Backyard Products GABLE - BACK WALL GABLE PANELS; PARTS REQUIRED FOR GABLE PANELS; INSTALLING GABLE PANELS

Right panel has square edge.
Left panel has lip edge.
29
1-1/4" (3 cm)
4
You will assemble (2) RIGHT and (2) LEFT wing walls.
Place OY on oor. Place a wing wall panel primed side down onto OY
.
3
1
Secure panel ush to edges with (8) 1-1/4 screws spaced 10" apart.
You have nished building (2) sets of wing wall assemblies.
Set (1) LEFT and (1) RIGHT wing walls aside. Continue building your back wall.
BEGIN
DOOR
Flush
2-1/2"
(6,35 cm)
2-1/2"
(6,35 cm)
x2
x2
Use 2x3's
for support.
10" (25,4 cm)
Approximately
OY
Primed Side
Down.
Fig A.

to these edges.
WING WALL PANELS
PARTS REQUIRED:
x32
2 x 3 x 72" (5 x 7,6 x 183 cm)
x4
OY
x2
x2
LEFT
RIGHT
