Backyard Products GABLE - FRONT WALL FRAME ASSEMBLY; PARTS REQUIRED FOR FRONT WALL FRAME; ASSEMBLING THE FRONT WALL FRAME

Use a 2x3"
for support.
Flush
6"
(15,cm)
6"
(15 cm)
Flush
30
Secure wing wall assemblies to back wall frame with
2" nails spaced 6" apart.
Place wing wall assemblies on frame with bottom of panels ush.
5
Your wing walls are now installed.
FINISH
Do not nail
in groove.
DOOR
LEFT
RIGHT
HINT:
To draw panels tight at
seams angle nail.
BACK WALL PANELS
2" (5 cm)
x1
x24
x1
PARTS REQUIRED:
LEFT
RIGHT
Pre-assembled
Pre-assembled
Primed side UP
Primed side UP
