Backyard Products GABLE - FRONT WALL PANELS INSTALLATION; PARTS REQUIRED FOR FRONT WALL PANELS; INSTALLING LEFT FRONT WALL PANEL

x1 RIGHT
x1 LEFT
31
DOOR
HINT:
To draw panels tight
at seams angle nail.
x6
BACK WALL GABLE PANELS
2" (5 cm) x6
PARTS REQUIRED:
3/4" GAUGE
BLOCK
GAA
2
4
3
Use a 3/4" gauge block at edge of panel. Secure with 2" nails along edge as shown.
Secure panels with 2" nails along edge, as shown.
Place left gable panel onto frame primed side up and ush to left panel.
NOTE: Panel grooves will not align.
Place right gable panel onto frame primed side up and ush to left panel.
NOTE: Panel grooves will not align.
You have nished building your back wall.
FINISH
5
1
BEGIN
Primed side UP
Primed side UP
Flush
Flush
Gauge Block
Use a 2x3"
for support.
Use a 2x3"
for support.
Do not nail
in groove.
3/4"
(1,9 cm)
