Backyard Products GABLE - FRONT WALL INSTALLATION; ORDER OF FRONT WALL INSTALLATION; SECURING FRONT WALL TO FRAME

2
Be sure the measurement between the panel
edge and the trim is the same along the entire
length. Then secure with (1) 2" nail in the upper
corner (Fig. D).
Secure the panel edge to the trim with 2" nails
spaced 6" apart.
Secure the front wall frame with (2) 3" screws
(Fig. E).
Screw through the front wall trim into the top
and bottom plates using (1) 3" screw (Fig. F).
Repeat process to secure the right side of
the front wall.
3
Center front wall on oor side-to-side.
The side wall soft will overlap the front
wall 3/8" (Fig. A).
Nail the front wall ush to the oor using
2" nails spaced 6" apart. Angle nails to hit
oor frame (Fig. B).
Nail the lower side wall corner to the front
wall trim with (1) 2" nail (Fig. C).
1
BEGIN
6"
(15 cm)
2" (5 cm)
Nail
6"
(15 cm)
Same
Measurement
Side
Panel
Fig. D
Trim
2" (5 cm)
Nail
50
2" (5 cm)
3" (7,6 cm)
FRONT WALL INSTALLATION
x8
x36
DOOR
Fig. E
3" (7,6 cm)
Screw
3" (7,6 cm)
Screw
3" (7,6 cm)
Screw
Fig. F
3" (7,6 cm)
Screw
2 x 3"
CENTER
6"
(15 cm)
6"
(15 cm)
2" (5 cm)
Nail
Fig. C
Trim
2" (5 cm)
Nail
Fig. B
Fig. A
Trim
Panel

Panel
3/8" (0,9 cm) OVERLAP
