Assembly Instructions (continued)
12
Attach Left Side Shelf
Note: Leave 5 mm of bolt threads exposed.
C
x 2
11
Attach Grill Body Assembly
B
x 4
F
x 4
G
x 4
10
Attach Temperature Gauge
9
Attach Doors
H
x 2
