Hardware
Tools Required for Assembly ( Included)
1
Lid G1503-020
2
Brand Plate* B0109-LA1
3
Warming Rack G1203-100
4
Cooking Grid G1203-110
5
Handle G1203-010
6
Heat Plate (2) G1203-120
7
Top Hinge (2) G1503-030
8
Bottom Hinge (2) G1503-040
9
Left Side Shelf G1503-130
10
Grease Cup B0219-D01
11
Grease Cup Support B0220-D01
12
Upper Left Cart Frame G1703-01A
13
Cart Frame Inserts (4) G0900-110
14
Grill Body Assembly* G1503-050
15
Burner (2)* G1503-060
16
Igniter* B0217-H01
17
Control Knob (2) G1503-080
18
Regulator/Hose Assembly* G1646-130
19
Upper Right Cart Frame G1703-02A
20
Right Side Shelf G1503-130
21
Cart Frame Support
Wire A (2)
G1703-03A
22
LP Gas Tank Heat Shield G1503-190
23
Rear Cart Frame
Support (2)
G1503-290
24
Lighting Hook* B0223-D04
25
LP Gas Tank Retainer Wire G1503-210
26
Lower Left Cart Frame G1703-04A
27
Lower Right Rear Cart Frame G1703-06A
28
Lower Right Front Cart Frame G1703-05A
29
LP Gas Tank Block Wire G1308-300
30
Front Panel G1703-07A
31
Axle G1503-310
32
Wheel (2) B0302-E01
* Pre-assembled
#2 Phillips Head Screwdriver 1 pc M10-M5 Wrench 2 pcs
A
Screw
ST4.8x10 Nickel Plated Phillips
Truss Head
8 pcs
B
Screw
M5x14 Nickel Plated Phillips Truss
Head
29 pcs
C
Screw
M6x15 Nickel Plated
2 pcs
D
Bolt
M5x16 Nickel Plated Hex Head
8 pcs
E
Nut
M5 Nickel Plated
8 pcs
F
Nut
M10 Nickel Plated
2 pcs
G
Wing Nut
M6 Nickel Plated
2 pcs
H
Washer
ø5.4 Nickel Plated
12 pcs
I
Washer
ø6.4 Nickel Plated
2 pcs
J
Washer
ø6.4 Heat Resistant
2 pcs
K
Lock
Washer
ø5.4 Nickel Plated
12 pcs
L
Lock
Washer
ø6.4 Nickel Plated
2 pcs
M
Pin
ø6x30 Nickel Plated
2 pcs
N
Cotter Pin
ø1.4x30 Nickel Plated
2 pcs
O
Spacer 2 pcs
Parts List
