NOTE:

USE 1 1/4" BOLTS TO FASTEN EACH

SIDE OF THE SLIDE SUPPORT TUBES.

009

(x4)

BOLT - 1 1/4"

TIP:

HAV

ING A HELPER HOLD THE SLIDE

ASSEMBLY TOGETHER WHILE YOU FASTEN

WILL MAKE IT EASIER TO ASSEMBLE.

QTY

PART NUMBER DESCRIPTION

4 H100009 BOLT WH 5/16x1 1/4

STEP 5 - SLIDE ASSEMBLY
