NOTE:
USING AN 1/8" DRILL BIT, DRILL PILOT HOLES IN EACH INDENTATION ALONG
EACH SIDE RAIL. THERE SHOULD BE 15 INDENTATIONS ON EACH RAIL. BE
SURE TO DRILL THROUGH THE SLIDE RAIL AND THE SLIDE BED. THEN SECURE
WITH THE PROVIDED HARDWARE.
090
(x30)
SCREW - 2 1/2"
QTY
PART NUMBER DESCRIPTION
30 H100090 SCREW PFH 8x2 1/2
STEP 6 - SLIDE ASSEMBLY
74
