PAGE 51
42" MZ & 48" 54" MZ Magnum- Chute Assembly
DESCRIPTION
PART NUMBER
QTY
ITEM
Chute Hanger
206-6020-00
11
Discharge Chute Bracket MZ (Upper)
039-4891-00
1
2
Rubber Discharge Chute MZ (Component)
210-6015-0013
5/16" Nylon Flange Nut
013-8049-00
9
4
5/16-18x3/4 carriage bolt
018-8062-009
5
.360 ID Plastic Washer
019-6042-0026
Discharge Chute Bracket MZ (Lower)
039-4890-00
17
Parts 2,3,5,7,8 Make's up the Mz discharge Assembly
210-6015-98
1
8
3
2
7
1
4
8
4
4
5
5
5
6
