The pump belt tensioner is located under the engine and has
a grease fitting at its pivot point. Grease at every engine oil
change.
The deck belt tensioner is located at the rear of the deck and
has a grease fitting on its pivot point. Grease at every engine
oil change.
The control arm blocks have grease fittings located on the
top and bottom of each block. Grease one time a year.
SECTION 6: CUTTING DECK
To remove the deck belt, lift up on the belt while rotating the
pulley to roll the belt up and off of the pulley. (be sure not to
get your fingers between belt and pulley).
To check the level of the deck, start on a flat surface and
set the air pressure in all four tires. Raise the deck up, and
measure all four corners of the deck to see if it is level from
left to right and front to back. All decks should be level from
left to right and have a 1/8˝ pitch down in the front.
If deck adjustments are necessary, start with the chain
length adjusters. These adjusters affect the overall height of
the deck and the level from left to right.
PAGE 19
