Bad Elf Flex Mini - Device Specifications; Positioning Engine Details; Positioning Performance Metrics

Specifications
Communications
USB
USB 2.0 device via USB-C receptacle
Bluetooth
Bluetooth V4.0 (HS) with integrated Class 1.5 PA, Supports 3 simultaneous
connections
Positioning Engine
GPS
L1 C/A, L5
GLONASS
L1
Galileo
E1, E5A
BeiDou
B1l, B2a
QZSS
L1
Note: constellations and frequencies are dependent on Flex Mini configuration and subscriptions.
Positioning Performance
Horizontal accuracy
CES (50%)
2DMRS (95%)
RTK
Standard: N/A
TBD
Extreme: 0.25cm
SBAS
Standard: 1-2m
TBD
Extreme: ~1m
Autonomous
2.0-2.5m
TBD
Timing (1PPS) accuracy
20 ns
Cold start time
< 60 s typical (no almanac or RTC)
Warm start time
< 30 s typical (almanac and RTC)
Hot start time
< 10 s (almanac, RTC, and position)
Maximum speed
1,850 kph (999 kts)
Maximum altitude
18,288 m (60,000 ft)
