Digital air- conditioner controller KR- 454
3.1. OPERATION, DRIVER'S COCKPIT (FRONT BOX)
S15 S16 Setting the setpoint for the temperature of the driver's cockpit
Setting- and display range 0-100% in 1%-steps with the standard
model without air-conditioning. With air-conditioned front box with
incorporated temperature sensor the display of the setting range
has got a decimal dot. Display range from
F 0.0
to
F10.0
.
The actual setpoint of the driver's cockpit is displayed by a short
pressing (press and release) of keys
S15
or
S16
.
Display f.ex.“
F50
“ or “
F5.0
“.
You can change the setpoint in 1%-steps per key pressure with
keys
S15
and
S16.
If you press any key for more than 2 seconds
the setpoint is changed at a high speed.
If you don't press any of these keys the actual setpoint is stored
and displayed. The display goes back to its former status after 5
seconds.
S1: Front box fan 40%
Also functions without the engine running
S2: Front box fan 100%
Functions only when the engine is running
S3:
Flap “Fresh air/circulating air“, driver's cockpit
Basic setting: Fresh air
S4 Flap “Screen defrost“
Basic setting: flap open
INDUSTRIE-ELEKTRONIK
Control and regulating systems for vehicle air conditioning
D-71691 Freiberg a.N., Siemensstr.21
Phone: +49 7141 / 68877 - 0 Fax: +49 7141 / 68877 - 39
page: 7
of: 42
04541530.SDW
Issue: October 1998 - Copyright (C) BADER GmbH - Alterations reserve
