Digital air- conditioner controller KR- 454
S17 S18 Setting the setpoint for temperature upper deck
Setting- and display range from 18°-28° C
The actual setpoint of the upper deck is displayed by a short
pressing (press and release) of keys
S17
or
S18
.
Display => f.ex. “
20
“
You can change the setpoint with keys
S17
and
S18
in 1°C -steps
per key pressure.
The actual setpoint is displayed after releasing the corresponding
key.
If you don't press the keys for further 5 sec. the value is stored and
the display goes back to its former status.
S19 S20 Setting the setpoint for temperature lower deck
Setting- and display range from 18°-28° C
The actual setpoint of the lower deck is displayed by a short
pressing (press and release) of keys
S19
or
S20
.
Display => f.ex. “
20
“
You can change the setpoint with keys
S19
and
S20
in 1°C -steps
per key pressure.
The actual setpoint is displayed after releasing the corresponding
key.
If you don't press the keys for further 5 sec. the value is stored and
the display goes back to its former status.
S6 AUTOMATIC MODE
The temperature control system of the passenger compartment is
switched on automatically after starting the engine. The LED of
key
S6
flashes. You can switch off the Automatic mode by
pressing key
S6
. Automatic control is only possible with the engine
