BAFANG 8FUN - Connection Diagram

27
gap distance ≤ 5mm
fix the nut after adjust appropriate position
4 Connection diagram
a) Brake sensor
b) Brake sensor
c) Display
d) Throttle
e) EB-BUS cable
f) Battery
g) Speed detecting sensor
Motor,
controller,
p
edal senso
r
Battery
