BAFANG M400 User Manual

3
USER MANUAL FOR MOTOR
BF-UM-C-MM G330-EN October 2019
6.2 SPECIFICATIONS
① Motor model: MM G330.250.C / MM G330.250.CCB
Rated power (W) 250
Rated voltage (V) 36 / 43 / 48
Waterproof IP65
Certification CE / ROHS / EN14766 / EN14764
Outdoor Temperatures -20℃~45℃
② Motor model: MM G330.350.C / MM G330.350.CCB
Rated power (W) 350
Rated voltage (V) 36 / 43 / 48
Waterproof IP65
Certification CE / ROHS / EN14766 / EN14764
Outdoor Temperatures -20℃~45℃
6.2.1 Surface
Shockproof black or silver gray coating
6.2.2 Storage Information
The pedelec should be stored in a ventilated humid and dry room. Avoid storing the pedelec near strong
magnetic objects.

BAFANG M400 Specifications

General

Type	Mid-drive motor
Nominal Voltage	36V
Rated Power	250W
Max Torque	80 Nm
Weight	3.9 kg
Efficiency	≥ 80 %
Protection Level	IP65
