REPAIR/REPLACEMENT PROCEDURES
3 Gently shde the assembly out Be careful not to d1sturb
other cabmet w1nng
4 Venfy that replacement assembly 1s the same ratmg as
the one just removed
5 Shde replacement assembly m
6
Secure w1th the four screws removed m Step 2
7
Plug power cord mto Power Entry Panel
8 Listen for fan rotat1on
POWER SUPPLY MODULE
Fuse Replacement
WARNING
AVERTISSEMENT
NOTE: Power Supp y modu as can be removed under power
Use a flat blade screwdnver to tum the two concentnc
screws one half tum m e1ther d1rechon Shde the module
part way out
To prevent shock when removing the Power Supply Module,
waH 5 seconds to allow line filter capacitors to discharge
before handling the module. Then, slide the module the rest
of the way out. Do not grab the module by the heat sink (it
may be hot); support It by the bottom edge of the circuit
board
Pour eviter les chocs electriques, attendre 5 secondes avant
de toucher au module afln de parmettre Ia dissipation de
l'energle emmagaslnee dans les condensateurs de filtration.
On peut ensulte retlrer le module complelement en le tlrant
vera sol. Ne pas tenlr le module au niveau du dlsslpateur
thermique, mais plutot au nlveau de Ia partie lnferleure de Ia
carte de dlrcults imprimes.
2 Grasp the faceplate handle and shde the module out
3 Once the module has cooled, lay >ton the anh statlc mat
4 Locate fuse Fl (at the rear of the module by the Pledge
connector See F1gure 3 6
5 Use a fuse removal tool to extract fuse Fl
6 Insert a new 2 amp slow blow fuse
POWER SUPPLY MODULE
I E96 506A 7 3
