4-45
Caravan Equipment
4
4.22.15 Testing the PIR
1. Press “F”, press “6”.
2. Walk in front of the PIR. The light on the keypad marked PIR will illuminate five times, and give a
n
audible signal.
4.22.16 Testing the Siren
1. Press
“F”, press “7”.
2. The siren will sound. Press “C” to stop the siren.
4.22.17 Testing the Tow Sensor
The towing vehicle must be connected to the caravan via the 12S plug before this test can be carried
out. This sequence also assumed that the towing vehicle is correctly wired.
1. Press “F”, press “8”.
2. The “FNC” light on the keypad will stay on.
3. Disconnect the car from the caravan. The siren will emit a short burst followed by five flashes on the
keypad tow sensor indicator, and give an audible signal.
4.22.18 Testing the Tilt Sensor
1. Press “F”, press “9”.
2. Adjust the level or move the caravan until one of the Tilt Sensor Indicators on the keypad illuminates
and gives an audible signal.
3. Press “C”.
4.22.19 Troubleshooting
1. When attempting to arm, on entering the personal code, sensor lights do not illuminate - The code
entered is incorrect, or all sensors are active. Check the tow vehicle is attached, that there is no one
in the PIR’s field of vision, connections to the PIR are good and that the caravan is level.
2. The tilt sensor light does not illuminate on arming - The tilt sensor is active. (Press ‘C’ to cancel then
refer to section ‘Setting up the Tilt Sensor).
3. The tow sensor light does not illuminate on arming - The 12S (grey) socket on the towing vehicle
must be correctly wired. Assuming this is the case then the vehicle may have been disconnected
from the caravan (e.g. when on site).
4. The PIR sensor light does not illuminate on arming - Ensure no one is in the PIR’s field of view,
including the person who is arming the system. Move everyone outside the PIR’s field of view and
press ‘1’. If the PIR indicator still does not light then check PIR connections.
5. On disarming the system the sensor indicators do not light - An incorrect personal code has been
entered.
6. If you are unable to resolve your problem please contact Plug-In-Systems Product Support
Department. Tel: 01482 659309.
