Specifications
Physical Characteristics
Dimensions 13 in. high x 10 in. deep x 11 in. wide
(33 cm high x 25 cm deep x
28 cm wide)
Weight 11.5 lb (5.2 kg)
Safety System
Thermostat
Bulb and capillary type
Over Heat Warning
If the temperature gets too high, the Over Heat warning
light on the front panel will illuminate and the alarm will
sound. The heat will shut off and the blower will continue
to run.
High Temperature Thermostat
The thermostat interrupts power to the heater and
activates the alarm at a preset high temperature of
53° ± 3°C (127.4° ± 5.4°F) or less at the end of the hose,
as determined by the Model 221 Temperature Test Kit or
Model 22110 Temperature Test Unit.
Temperature Characteristics
Air temperatures reaching the patient are approximately
2°C lower than the listed temperatures.
Operating Temperatures
Average temperature at the end of the hose:
HIGH: 43° ± 3°C (109.4° ± 5.4°F)
MED: 38° ± 3°C (100.4° ± 5.4°F)
LOW: 32° ± 3°C (89.6° ± 5.4°F)
Electrical Characteristics
Leakage Current
Meets regulatory standards for leakage current.
Motor
Fractional horsepower, single phase
Heater
An electric heating element
Fuses
10A, 200mA (110-120 VAC Units)
6.3A, 100mA (220-240 VAC Units)
10, 160mA (100 VAC Units)
Device Ratings
110-120 VAC, 60 Hz, 10 Amperes
220-240 VAC, 50 Hz, 4.5 Amperes
100 VAC, 50/60 Hz, 10 Amperes
Bair Hugger Model 505 Service Manual
19
