Baja Designs Squadron Pro - Page 4

4
7. Install the larger metal bracket to the
plastic shroud at the longer mounting
tab on the shroud. Use a 10mm socket
and a 4mm Hex key to install the M6
Button head along with a nut and
washer. Leave loose for now.
* Install the bolt such that the head is
towards the inside of the shroud*
6. Use a sharp blade to trim the
indicated tabs flat (Driver side pictured).
5. Plug in the connector pictured to
the OEM fog light connector and leave
the 2-pin weather pack out ready to
receive the Squadron connector.
