6.7 202 Islander
®
R
Speed changes you.
TM.
swItCh panel wIre InForMatIon (FIg 6.7.1)
#1
#2
#3
#4
PLUG 1
8 - Way Deutsch DT Series Receptacle
Receptacle DT04 - 08 PA
Secondary Lock W6-P
BLOWER
HORN
FIRE EXTINGUISHER
BOW LIGHT
#8
#7
#6
#5
16 AWG DARK BLUE
16 AWG DARK BLUE WITH A WHITE STRIPE
14 AWG BROWN
14 AWG GRAY WITH A WHITE STRIPE
14 AWG YELLOW WITH A BLACK STRIPE
14 AWG ORANGE WITH A YELLOW STRIPE
16 AWG RED WITH AN ORANGE STRIPE
16 AWG GRAY
#5
#4
#7
#8
# 1
# 2
# 3
# 4
STERN LIGHT
BILGE PUMP
COURT LIGHT
PANEL LIGHTS
PLUG 3
2 - Way Deutsch DTP Series Plug
Plug DTP06-2S
Secondary Lock WS-2S
#1
#212 AWG ORANGE
12 AWG BLACK
WIRE DROP GROUNDS#2# 1 12 VOLT
PLUG 2
6 - Way Deutsch DT Series Receptacle
Receptacle DT04-6P
Secondary Lock W6P
#6
#5
#4
#1
#2
#3
16 AWG PURPLE
16 AWG RED
16 AWG GREEN
16 AWG BLUE
14 AWG BLACK
14 AWG RED WITH AN YELLOW STRIPE
TRAILER
TRIM (POWER)
TRIM DOWN
#4
#5
#6
# 1
# 2
# 3
STEREO
GROUND
TRIM UP
(156) SPLASH PROOF
CONNECTOR RECEPTACLE
(250) HEAT SEALED
QUICK SLIDE RECEPTACLE
(155) SPLASH PROOF
CONNECTOR PLUG
B
C
A
16 AWG
BLUE/WHT
16 AWG
BLACK
COURT LIGHT
COURT LIGHT
36"
12"
5"
16"
10"10"
4"
4"
6"
6"
PLUG 1
PLUG 2
PLUG 3
16 AWG BLUE
TRIM UP
16 AWG GREEN
TRIM DOWN
16 AWG RED
TRIM POWER
16 AWG RED/ORN
FIRE BOY
16 AWG BLACK
FUME DET.
16 AWG RED/ORN
FIRE BOY
16 AWG RED/PINK
FUME DET.
TO BLOWER SWITCH
14 AWG YELLOW WITH A BLACK STRIPE
TO STEREO WIRE SWITCH
14 AWG RED WITH A YELLOW STRIPE
TO 12 VOLT
12 AWG ORN
TO FUME DET.
16 AWG RED WITH A PINK STRIPE
TO COURT LT SWITCH
16 AWG DK BLUE WITH A WHITE STRIPE
TO NAV/ANC LIGHT SWITCH
14 AWG RED WITH A GRAY STRIPE
TO HORN SWITCH
14 AWG ORN WITH A YELLOW STRIPE
TO BILGE SWITCH
14 AWG BROWN
TO FIRE BOY WIRE DROP
16 AWG RED WITH AN ORANGE STRIPE
COURT LT.
BLOWER
2 AMP
5 AMP
NAV/ANC
5 AMP
STEREO
2 AMP
HORN
5 AMP
STEREO MEM
2 AMP
BILGE
4 AMP
12 VOLT
15 AMP
FIRE BUOY
2 AMP
FUME DET.
2 AMP
ACC
10 AMP
ACC
STEREO
BILGE
BLOWER
LT
COURT
TRIM
TRAILER
LTS
NAV/ANC
HORN
