CARBURETTOR SPECIFICATIONS
Pulsar 150/180 DTS-i
Service Station Manual
28
Dealer Development Center
Akurdi Pune
Carburettor
Carburettor Specifications of Pulsar 180 cc :
Make and Type Ucal-Mikuni BS26, CV type
Identification No. DJ - U4
Idling Speed 1400 100
VC Screw setting 2.5 2 turns out
Main Jet 112.5
Jet needle mark 4078
Needle jet mark P-1
Jet needle clip Position 2nd from top
Pilot Jet 17.5
Starter jet Fixed type
Throttle valve Fixed type
Choke Lever 2 stage with push pull type
mechanism (ON / OFF)
+
+
DJ-U4
BS29 9321 B
Carburettor Specifications of Pulsar 150 cc :
Make and Type Ucal-Mikuni BS26, CV type
Identification No. DH - U3
Idling Speed 1400 100
VC Screw setting 2.5 2 turns out
Main Jet 107.5
Jet needle mark 4DMP23
Needle jet mark P-1
Jet needle clip Position 2nd from top
Pilot Jet 12.5
Starter jet Fixed type
Throttle valve Fixed type
Choke Lever 2 stage with push pull type
mechanism (ON / OFF)
+
+
B DH-U3
BS26 6X27

Bajaj pulsar DTS-i Specifications

General

Fuel System	Carburetor
Transmission	5-speed
Kerb Weight	144 kg
Bore	57 mm
Compression Ratio	9.5:1
Wheelbase	1320 mm
Ground Clearance	165 mm
Engine Type	4-stroke, Air-cooled, DTS-i
Front Brake	Disc
Rear Brake	Drum
Front Suspension	Telescopic
Rear Suspension	Nitrox Shock Absorber
Fuel Tank Capacity	15 L
Clutch	Wet Multi Plate
Frame Type	Double Cradle
Rear Tyre	100/90 x 17 - 55 P
Starting	Self/Kick Start
