BAK Thermoplastic Welding Technology Ltd 4
SECURITY ADVICE
The following warning symbols show the existent risks:
Risk of crushing Risk of burns
The operator is responsible for the compliance of the safety related standards.
Before starting up of the machine the operator must be instructed about these standards.
TECHNICAL DATA
Voltage V 230
Frequency Hz 50
Power consumption W 3500
Max. power input A 15.5
Temperature °C 20 – 600
Drive m/min. 0.6 – 12.0
Max. air flow (20°C) l/min. 500
Noise level (EN ISO 11203) dB(A) 64
Dimensions mm (L x B x H) 460 x 360 x 310
Weight with 5m cable kg 14
Protection class IP20
Conformity symbol
Protection class 1
Available on demand in 120V. Other voltages on request.
DESCRIPTION OF FUNCTIONS
Heating system:
The hot air temperature is steplessly adjustable and electronically controlled. According to the
material thickness the nozzle can be adjusted steplessly.
Welding pressure:
The welding pressure can be changed by addition or reduction of weight.
Drive:
The drive is steplessly adjustable and electronically controlled. The control system is designed
in a way, that the adjusted speed remains constant, independent from the load.
