Baker BP Dominator 3650E - Page 36

36
Inspection and Maintenance: (continued)
 TWICE DAILY - Grease the clamp arm up/down & in/out; fence arm up/down; and toe
roller up/down. We recommend JT-6 grease.
Figure 32
Figure 32C
Figure 32A
Figure 32B
Clamp arm grease
fittings (back side)
Clamp arm
grease fittings
(front side)
Toe roller grease
fitting (backside)
Fence arm grease
fitting
