Balboa Clim8zone - CLIM8 ZONE Diagram and Dimensions

432.3 mm
17.0”
444.0 mm
17.5”
474.0 mm
18.7”
406.4 mm
16.0”
432.3 mm
17.0”
TOP
474.0 mm
18.7”
430.0 mm
xxxxx
RIGHT
LEFT
BACK
FRONT
5 44
6
8
7
9 10
22
43
794.1 mm
31.3”
11
1
TM
INSTALLATION GUIDE 42391 Rev A
Balboa Water Group | Your Single Source Solution
7
6
CLIMZONE
TM
DIAGRAM & DIMENSIONS
1 Enclosure Lid
2 Mounting Feet
3 Fan
4 Air Vents
5 Condensation Drain Spout
6 Lid Screws
7 Water Output
8 Water Input
9 Control / Data Bus
10 Power Line Box
11 Bonding Lugs (North America)
Figure 1 Figure 2
