Section 2. Installation
the panel, and cover the instrument with suitable
protective covering such
as
a plastic bag or strong
craft paper.
If
the instrument incorporates a
rechargeable battery (Option 05); first, fully charge
the battery. Place power cable and other
accessories with the instrument. Store the covered
voltmeter
in
a clean dry area that
is
not subject to
extreme temperature variations or conditions which
may cause moisture to condense on the instrument.
2-9.
LONG
TERM
STORAGE
OR
REPACKAGING
FOR
SHIPMENT
If
the instrument is to be stored for a long period or
shipped, proceed as directed below.
If
you have
any questions contact your local Ballantine field
engineering representative or the Ballantine Service
Department at the factory.
If
the original Ballantine supplied packing
is
to be
used proceed as follows:
a.
If
the original wrappings, packing material
and container have been saved, repack the
instrument and accessories originally shipped to
you.
If
the original container
is
not available, one
may be purchased through the Ballantine Service
Department at the factory.
b.
Be sure the carton is well sealed with strong
tape or metal straps.
c.
Mark the carton with the model number and
serial number with indelible marking.
If
it
is
to be
shipped, show sending address and return address
on two sides
of
the box; cover all previous shipping
labels.
If
the original container
is
not available, proceed as
follows: (See Figure 2-4).
a.
Before packing the unit, place all accessories
into a
p'lastic bag and seal the bag.
b.
For extended storage or long distance
shipping only, use U.S. Government packaging
method II C and tape a two-unit bag
of
desiccant
(per MIL-D-3464) on the rear cover.
c.
Place a
13
cm
(5
inch) by 20 cm
(8
inch)
piece
of
sturdy cardboard over the front panel for
protection.
d.
Place the voltmeter into a plastic bag and
NOTE: DIMENSIONS
ARE
IN INCHES
AND
(MILLIMETERS).
11.83
--------
(300)
----.l
___
.10.52
(267)
5.21
(132)
.07
typo
( I )
5.81
(147)
• I
---*-
page 2-2
