Installation and operating manual VARIABOX
EN
(11.2016)
11 / 20
Wall mounting
For use as a wall combination, the VARIABOX must be fixed with plugs and screws to the wall (fas-
tening set is available in our accessories).
You have two options available for this purpose. One option is to use the outer fastenings as descri-
bed below.
The other option is that the screw connection to the wall takes place through the threaded shafts for
the captive housing screws (Design and function [} 8]). The shafts are intended for 6 mm screws.
1. Loosen the screws of the outer fastenings on the back side of the VARIABOX and push them
out either downwards or upwards.
2. Tighten the screws again.
3. Hold the VARIABOX against the wall and mark the boreholes.
6.2
