4. Drill the holes and insert suitable plugs into them.
5. Fix the bottom screws in place. Make sure that the screw heads have sufficient clearance to
the wall, in order to hook in the VARIABOX.
6. Break out the cable entry provided for the supply cable and put the cable gland in place. The
supply cable can be routed either from the bottom or from the top into the VARIABOX.
7. Place the VARIABOX with the outer fastenings on the lower screws.
8. Fix the VARIABOX with screws to the four outer fastenings on the wall.
ð This completes the wall mounting.
Connecting the supply cable
DANGER
Electrical voltage
The supply cable may carry high electrical voltage that is fatal. Pay attention to the five safety rules of
electricity:
1. De-energise.
2. Secure the supply from being switched on again.
3. Ensure the de-energised condition.
4. Connect to earth and short circuit.
5. Cover or cordon off adjacent live parts.
Choose the required cable cross-sections and line fuses based on the specifications given on the
nameplate (see Design and function [} 8]).
1. Loosen the captive housing screws and open the VARIABOX.
2. Press the brackets of the supporting rails inside and pull the supporting rails out from the
front.
3. Strip the cable such that the sheath reaches about 1 cm wide through the cable gland in the
VARIABOX. Remove the insulation from the cable cores.
6.3
Installation and operating manual VARIABOX
(11.2016)
12 / 20
